Technical Specifications
Ace grab-type garbage truck, 5-6.3 tons.
Vehicle Model: Chengli Brand: CL5160ZZD6BL
Overall vehicle dimensions: Length: 6860, 7320, 7790, 8250 mm x Width: 2420, 2520 mm x Height: 3850 mm;
Wheelbase: 3600 (single row), 3900, 4200, 4500 mm
Cargo box dimensions: 4000, 4100, 4500, 5050 x 2300, 2400 x 800
Gross vehicle weight: 16200KG; Curb weight: 9580, 8780KG
Chassis Configuration
Sinotruk Wangpai new cab, Weichai 190hp engine, 10-ton rear axle (1530), 245×(10+8) partially double-layer beams, 9.00R20 steel radial tires, factory-installed electronic air conditioning, multi-function steering wheel (MP3 + Bluetooth), metallic paint, central locking, power windows, remote key, vehicle satellite positioning terminal, right-turn voice alarm. Note: The only 3900mm wheelbase extended cab with a 1534 rear axle (9-ton Wangpai).
[Upper body configuration]
Chengli 5/6.3-ton truck-mounted grabber with 3-section folding boom, maximum boom length 8.2 meters, maximum working height 11.2 meters. Equipped with an electronically controlled three-valve system, excavator-like operating handles, and standard hydraulic radiator, the entire crane and grab can rotate 360° infinitely. The grab type can be selected according to actual working conditions, either a 3+2 grab or a 4-lobed grab, offering strong lifting capacity and fast loading speed. All hydraulic components are imported or from top domestic brands, ensuring low failure rate and excellent after-sales service. Optional features include a log grapple and a reverse-folding grabber (increasing cargo box size by 300mm).
【Cargo compartment configuration】
The side 3-bottom 5-top double-top dump truck body has a densely reinforced cargo box lining, 160mm channel steel with 140mm interlocking for the side door support posts, front and rear balance beams, and four tilting seats.
